An extensive range of scopes to suit all calibres and disciplines.
All Vantage riflescopes feature our H2 optics in a variety of configurations.
- Capped Low-Profile Turrets
- 1 Inch Mono-tube chassis
- 11 layer Fully Multi-Coated lenses
- High torque zoom ring
- Fast focus eyebell
Nitrogen purged. Shockproof. Waterproof. Fog proof.
All calibre rated.
Hawke Warranty.
Mil Dot Reticle
The classic Mil Dot features multiple aim points for hold-over and hold-under. Accurate mil spacing on 10x, featuring 4 Mil Dots in each direction.
30/30 Duplex Reticle
A variant on the classic L4 reticle, the 30/30 Duplex offers 30″ spacing from post to post at 100yds, when on 4x magnification
Objective Lens
32mm
Reticle
30/30 Duplex
Parallax
Fixed
Magnification
4x
Optical System
System H2
Focal Plane
SFP (Second Focal Plane)
Scope Tube
1 Inch
Illumination
N/A
Field of View
28.5ft @100yds
9.5m @100m
Field of View (°)
5.4
Eye Relief
3.5in
90mm
PX/Focus
100yds
91m
Exit Pupil
0.31″
8mm
Turret Type
Capped
Turret Caps
YES
Click Value
1⁄ 4MOA
Elevation Turret Clicks (max)
165 MOA
Windage Turret Clicks (max)
165 MOA
Ocular Type
Fast Focus
Power Selector
Knurled Posi-Grip
Lens Coating
Fully Multi-Coated - 11 Layers
Length
11.6in
295mm
Weight
11.1oz
315g
-
SUPPLIED WITH
Box
Instruction Manual
Lens Covers
Lens Cloth
