LE2-16 | Pard Leopard 256 (16mm) Thermal Monocular

LE2-16 | Pard Leopard 256 (16mm) Thermal Monocular

PARD
SKU:
LE2-16
Availability:
WILL COME DIRECT FROM SUPPLIER ANY DELAYS YOU WILL BE NOTIFIED. FREE SHIPPING. CALL TO CHECK ON AVAILABILITY BEFORE ORDERING.
$1,089.00
Current Stock:
Adding to cart… The item has been added
Description

  • Pard Leopard 256 (16mm) Thermal Monocular

    The Pard Leopard 256 (16mm) Thermal Monocular offers cutting-edge thermal imaging technology in a compact and durable design. Equipped with an uncooled VOx sensor and a 256x192 pixel resolution, it delivers crisp thermal images, detecting heat signatures up to 800 meters away. The device features a 16mm objective lens with 2.9x optical magnification and digital zoom up to 8x, providing excellent range and clarity in all environments.

    With an OLED display resolution of 1024x768, multiple scene modes, and various image color palettes, the Leopard 256 ensures you capture clear thermal images in a variety of conditions. The device also includes built-in 32GB storage, photo and video recording capabilities, and supports wireless connections via Wi-Fi with the PardVision2 app. Designed for rugged conditions, it boasts IP67 protection and operates in extreme temperatures from -30°C to +55°C.

    Key Features:

    • 256x192 thermal sensor with 12µm pixel size
    • Detection distance up to 800 meters
    • 16mm objective lens with 2.9x optical magnification
    • 1024x768 OLED display with multiple scene and image modes
    • Photo and video recording with built-in 32GB storage
    • Wi-Fi connectivity and PardVision2 app support
    • IP67 water and dust protection
    • Battery life up to 6 hours with rechargeable 18650 battery

    Range Specifications (LE2-16)

    Model LE2-11 LE2-16
    Sensor
    Type Uncooled VOx(vanadium oxide)
    Resolution(pixel) 256*192
    Pixel Size(µm) 12*12
    NETD ≤25mK（0.025℃）
    Frame Rate(Hz) 50
    Detection Distance(m) 500/800
    Optics
    Objective Lens(mm) 11 16
    Optical Magnification(x) 2 2.9
    Digital Zoom(x) 2/4/6/8
    Field of view Horizontal 15.9° 11°
    Vertical 12° 8.2°
    Diagonal 19.8° 13.7°
    Eye Relief(mm) 20
    Diopter Adjustment(D) -5~5
    Display
    Type OLED
    Resolution(pixel) 1024*768
    Scene Mode City/Rain/Forest
    Image Mode WT-HOT/BK-HOT/RD-HOT/IN-HOT/SKY
    Photo / Video
    Photo Resolution(pixel) 1024*768
    Photo Format .JPG
    Video Resolution(pixel) 1024*768
    Video Format .MP4
    Storage Built-in EMMC (32 GB)
    Image Engine Pard IREA
    Main function
    PIP Yes
    Gyroscope Yes
    Loop Recording Yes
    Hot Track Yes
    E-compass Yes
    Shutter Mechanical shutter
    Microphone Yes
    Firmware Upgrade Yes
    Connections
    USB Tpye-C Yes
    WiFi Yes
    Supported Apps PardVision2
    Power Supply
    Battery Type Lithium Ion 18650*1
    Output Voltage(V) 3.7
    Operating Time(h) ≤6
    External Power Supply(V) Type-C
    Environmental characteristic
    Degree of Protection IP67
    Operating Temp(°C/°F) -30 ~ +55 / -22 ~ +131
    Measurement
    Product Dimension(with LRF, L * W * H, mm) 172*36*48
    N.W/pcs(with battery, g) 300
